MSI PRO X670-P WIFI DDR5 AMD AM5 ATX Motherboard
Quick Overview
- Model: PRO X670-P WIFI
- Supported CPU: Ryzen 7000 Series Processors
- for Socket AM5
- Supported RAM: 4x DDR5, Max 128GB
- Graphics Output: 1x HDMI, 1x Display Port, 1x
- Type-C Display port
- Features: 2.5G LAN with Wi-Fi 6E Solution
Original price was: ৳ 44,710.00.৳ 38,500.00Current price is: ৳ 38,500.00.
Availability:
In stock
Email to a Friend:
Description
Specification | |
Brand | MSI |
Model | PRO X670-P WIFI |
Supported CPU | Supports AMD Ryzen 7000 Series Desktop Processors |
Socket AM5 | |
Chipset | AMD X670 |
Form Factor | ATX |
243.84mmx304.8mm | |
Audio | Realtek ALC4080 Codec |
7.1-Channel High Definition Audio | |
Supports S/PDIF output | |
Supports up to 32-Bit/384 kHz playback on front panel | |
Expansion Slots | |
PCI | 3x PCI-E x16 slot |
Supports x16/x4/x2 | |
1x PCI-E x1 slot | |
PCI_E1 PCIe 4.0 supports up to x16 (From CPU) | |
PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) | |
PCI_E3 PCIe 4.0 supports up to x4 (From CPU) | |
PCI_E4 PCIe 4.0 supports up to x2 (From Chipset) | |
Memory | |
Type | DDR5 |
Slots | 4 DIMMs |
Supported Memory | Dual Channel DDR5 |
Maximum Memory | 128GB |
Graphics | |
Graphics | 1x HDMI |
Support HDMITM 2.1 FRL, maximum resolution of 4K 120Hz | |
1x Display Port | |
Supports DP1.4, maximum resolution of 4K 60Hz | |
1x Type-C Display port | |
Supports DisplayPort 1.4 with HBR3, maximum resolution of 4K 120Hz | |
Connector & Ports | |
HDMI | 1x HDMI |
Display Port (s) | 1x Display Port |
USB (s) | 4x USB 2.0 ports (Front) |
4x USB 3.2 Gen1 Type A ports (Rear) | |
4x USB 3.2 Gen1 Type A ports (Front) | |
2x USB 3.2 Gen2 Type A ports (Rear) | |
1x USB 3.2 Gen2 Type C ports (Rear) | |
1x USB 3.2 Gen2 Type C ports (Front) | |
1x USB 3.2 Gen2x2 Type C ports (Rear) | |
LAN Port (s) | Realtek RTL8125BG 2.5G LAN |
Wireless Communication module | AMD Wi-Fi 6E |
The Wireless module is pre-installed in the M.2 (Key-E) slot | |
Supports MU-MIMO TX/RX | |
Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands | |
Supports 802.11 a/ b/ g/ n/ ac/ ax | |
Supports Bluetooth 5.2 | |
Supported Storage | 4x M.2 slot |
M.2_1 (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280 devices | |
M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices | |
M.2_3 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices | |
M.2_4 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices | |
6x SATA 6G port | |
RAID | Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices |
Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices | |
Internal I/O Ports | 1x Power Connector(ATX_PWR) |
2x Power Connector(CPU_PWR) | |
1x CPU Fan | |
1x Pump Fan | |
6x System Fan | |
2x Front Panel (JFP) | |
1x Chassis Intrusion (JCI) | |
1x Front Audio (JAUD) | |
1x Tuning Controller connector(JDASH) | |
2x Addressable V2 RGB LED connector (JARGB_V2) | |
2x RGB LED connector(JRGB) | |
4x USB 2.0 ports | |
4x USB 3.2 Gen1 Type A ports | |
1x USB 3.2 Gen2 Type C ports | |
Warranty Information | |
Manufacturing Warranty | 3 Years Warranty |
